Corrugated Metal Roofing Sheet
Name: Corrugated Metal Sheet, Corrugated Galvanized Steel Roofing Sheet, Corrugated Galvalume Roofing Tile, Corrugated Aluminum Roofing Tile, Corrugated Stainless Steel Sheet, Corrugated Hot Dip Zinc-Aluminum Steel Sheet.
Effective width: 360mm-1050mm
Material width: 50mm-1250mm
Length: 200mm-12000mm customized
Height Of Wave: 76mm-380mm
Technical Standard: GB/T 12754-2006;ASTM A 755;EN 10169;JIS G 3312;AISI;BS;DIN
Material Grade: TDC51D+Z, TDC52D+Z, TDC53D+Z, TS280GD, TS350GD, TS550GD, DC51D+Z, DC52D+Z, DC53D+Z, S280GD+Z, S350GD+Z, S550GD+Z,TDC51D+AZ, TDC52D+AZ, TS250GD+AZ, TS300GD+AZ, TS350GD+AZ, TS550GD+AZ, DC51D+AZ, DC52D+AZ, DC53D+AZ, DC54D+AZ, S250GD+AZ, S300GD+AZ, S350GD+AZ, S550GD+AZ,Aluminum 1001, Aluminum 3003, Stainless 201, Stainless 304, Stainless 316,CGCC, SGCC,SGCH,SPCC
Color: Refer to RAL numbers Paton numbers or customer sample,common colors are ocean blue, white grey and bright red.
| Material: | PPGI | GI | PPGL |
| Thickness (mm): | 0.13-2.0 | 0.13-2.0 | 0.13-2.0 |
| Tolerance Of Thickness: | ±0.02mm | ±0.02mm | ±0.02mm |
| Coating Type: | Zinc | Zinc | 55%Galvalume |
| Coating(g/Sqm): | 40-275 | 40-275 | 40-180 |
| Painting Type: | PE PVDF | PE PVDF | |
| Top Painting(um): | 15-25 | 15-25 | |
| Bottom Painting(um): | 5-25 | 5-25 |
| Material: | GL | Aluminum | Stainless201/304 |
| Thickness (mm): | 0.13-2.0 | 0.4-2.5 | 0.3-1.6 |
| Tolerance Of Thickness: | ±0.02mm | ±0.02mm | ±0.05mm |
| Coating Type: | 55%Galvalume | ||
| Coating(g/Sqm): | 40-180 | ||
| Painting Type: | PE PVDF | ||
| Top Painting(um): | 15-25 | ||
| Top Painting(um): | 5-25 |
